LP-20 3+2 Pin Industrial Circular Waterproof Hybrid Connector
Code:LP-20-3+2
LP-20 3+2 Pin Industrial Circular Waterproof Hybrid Connector
Code:LP-20-3+2
| Combination Type | Power + Signal |
|---|---|
| Wiring method | |
| Locking Mechanism | Push-lock |
| Connection Type | |
| Mating cycles | 2000 |
| No. poles | 3+2 Pin |
| Rated current (AC/DC) | 10A+5A |
| Rated voltage (AC/DC) | |
| Cross-sectional area of a stranded conductor without a ferrule, min. (mm²) | 0.5 |
| Cross-sectional area of a multi-strand conductor without a ferrule, max. (mm²) | 1.5 |
| Cable diameter MAX (mm) | 12.0 |
| Cable diameter MIN (mm) | 10.0 |
| Maximum operating temperature | +85°C |
| IP Protection Rating | IP68 / IPX9K |
| Exterior Body | |
| Complies with product certification requirements | UL , TUV, CQC, CE, RoHS, REACH |
